Learning Math/CS/Engineering Design with Robotics
Ten Parallelograms
|
The above driveDistance() block drives the robot forward 5 units. The turnRight() allows the robot to move a certain number of degrees from the x-axis. The degrees can be modified by changing the block next to "angle". The while() block allows the student to loop the program a set number of times. For this activity, you will need to modify the given blocks to complete the parallelogram shapes shown on the board.
|
